MagHyst® adapters complement the device family with the option of direct measurement of the materials used by the company. In addition to the determination of the B(H) characteristics, the quality of the materials and parts can be evaluated e.g. as part of an incoming goods inspection.

MagHyst adapter for material measurement and customer-specific measurement tasks

MagHyst® adapters are available in the following versions:

MagHyst® rod adapter:

  • Determination of the B(H) characteristics
  • Rod diameter: 10mm
  • Minimum rod length: 120mm
  • Maximum excitation: 40kA/m
  • Dimensions: 11 x 7x 8cm, Weight: 2.0kg

MagHyst® sheet adapter:

  • Conducting comparative measurement
  • Sheet width: 25mm
  • Minimum sheet length: 125mm
  • Maximum sheet thickness: 3mm
  • Maximum excitation: 30kA/m
  • Dimensions: 18 x 11 x 14cm, Weight: 3.5kg

MagHyst® toroidal sample:

  • Determination of the B(H) characteristics
  • Outer diameter: 50mm
  • Inner diameter: 40mm
  • Height: 10mm
  • Maximum excitation: 30kA/m

The conducting of material measurements with the various adapters and the winding and measuring of toroidal samples is offered as a service. If you are interested, please contact us.
